Patent Issued for Selecting a medical device for use in a medical procedure (USPTO 11793572): Henry Ford Health System
2023 NOV 15 (NewsRx) -- By a
The patent’s inventors are Forbes, Michael (
This patent was filed on
From the background information supplied by the inventors, news correspondents obtained the following quote: “Non-invasive percutaneous implantation of cardiac devices poses certain challenges to physicians. As opposed to surgically invasive procedures, such as, for example, open heart surgery, physicians performing non-invasive cardiac implantation procedures have a limited field of view and are generally limited to guidance during the procedure using images generated by two-dimensional (2D) imaging modalities (e.g., ultrasound, fluoroscopy, etc.). Because physicians are typically limited to 2D imaging during the performance of a procedure, proper periprocedural planning and evaluation is required to accurately assess and determine, for example, the size of certain anatomical structures and the type(s) and/or size(s) of devices to be used during the procedure (e.g., catheters).
“As with in-procedure guidance, however, conventional periprocedural planning technology has generally been based on imaging platforms and modalities that employ 2D imaging. Accordingly, like the implantation procedure itself, periprocedural planning for such procedures poses challenges to physicians due to the inherent limitations of the conventional 2D imaging that is used.
“Accordingly, there is a need for a periprocedural planning method and system that minimizes and/or eliminates one or more of the above-identified deficiencies in conventional periprocedural planning methodologies/techniques.”
Supplementing the background information on this patent, NewsRx reporters also obtained the inventors’ summary information for this patent: “According to one embodiment, a method for selecting a medical device for use in the performance of a medical procedure is provided. The method comprises acquiring image data relating to an anatomical region of interest of a patient’s body, generating a multi-dimensional depiction of the anatomical region of interest using the acquired image data, defining a plurality of points relative to the multi-dimensional depiction, determining one or more measurements based on the defined plurality of points, and selecting a medical device to be used based on the determined measurements.
“According to another embodiment, a non-transitory, computer-readable storage medium storing instructions thereon is provided. The stored instructions are such that when they are executed by one or more electronic processors, the one or more processors are caused to carry out the method of: acquiring image data relating to an anatomical region of interest of a patient’s body; generating a multi-dimensional depiction of the anatomical region of interest using the acquired image data; defining a plurality of points relative to the multi-dimensional depiction; determining one or more measurements based on the defined plurality of points; and selecting a medical device to be used based on the determined measurements.
“According to yet another embodiment, a system for selecting a medical device of use in a medical procedure is provided. The system comprises an electronic processor and an electronic memory device electrically coupled to the electronic processor and having instructions stored therein. The processor is configured to access the memory device and execute the instructions stored therein such that it is operable to acquire image data relating to an anatomical region of interest of a patient’s body, generate a multi-dimensional depiction of the anatomical region of interest using the acquired image data, define a plurality of points relative to the multi-dimensional depiction, determine one or more measurements based on the defined plurality of points, and select a medical device to be used based on the determined measurements.”
The claims supplied by the inventors are:
“1. A method for selecting a medical device for use in the performance of a medical procedure, comprising: acquiring image data relating to an anatomical region of interest of a patient’s body; generating, with an electronic processor, a multi-dimensional depiction of the anatomical region of interest using the acquired image data, wherein the multi-dimensional depiction includes three dimensions; defining a plurality of points relative to the multi-dimensional depiction, wherein at least two of the plurality of points correspond to a centroid of an anatomical structure of the patient’s body, and wherein the plurality of points comprises two or more of the following individual points: a point within a mitral plane that contains a mitral annulus of the patient’s heart, wherein the point corresponds to a centroid of the mitral annulus; a point within an offset mitral plane that is a duplicate of and offset from the mitral plane, wherein the point is offset from the point in the mitral plane and corresponds to the centroid of the mitral annulus; a point within a fossa ovalis plane that contains a fossa ovalis of the patient’s heart, wherein the point corresponds to a centroid of the fossa ovalis; and a point within an inferior vena cava (“IVC”) ostium plane that contains an IVC ostium of the patient’s heart, wherein the point corresponds to a centroid of the ostium of the IVC; determining, with the electronic processor, one or more measurements based on the defined plurality of points, wherein the measurement(s) determined in the determining step comprise(s) at least one of: an angle formed by the point within the IVC ostium plane corresponding to the centroid of the ostium of the IVC, the point within the fossa ovalis plane corresponding to the centroid of the fossa ovalis, and the point in the mitral plane corresponding to the centroid of the mitral annulus, wherein the point within the fossa ovalis plane corresponding to the centroid of the fossa ovalis is the vertex of the angle; or an angle formed by the point within the fossa ovalis plane corresponding to the centroid of the fossa ovalis, the point within the mitral plane corresponding to the centroid of the mitral annulus, and the point within the offset mitral plane corresponding to the centroid of the mitral annulus, wherein the point within the mitral plane corresponding to the centroid of the mitral annulus is the vertex of the angle, and selecting a medical device over another medical device based on the determined measurements, wherein the medical device is configured to fit into an insertion point of interest.
“2. The method of claim 1, further comprising: identifying in the depiction the insertion point along an interatrial septum; selecting a model representative of the medical device that will pass through the interatrial septum during the performance of the medical procedure; importing the model of the medical device into the depiction, wherein the model is positioned within the depiction relative to the identified insertion point; and evaluating feasibility of the insertion point, a type, shape, and/or size of the medical device, or both the feasibility of the insertion point and the type, shape, and/or size of the medical device based on a trajectory of the model of the medical device within the depiction.
“3. The method of claim 1, further comprising receiving at least one user input, and in response to that at least one user input, the method further comprising: identifying in the depiction the insertion point along an interatrial septum; selecting a model representative of the medical device that will pass through the interatrial septum during the performance of the medical procedure; importing the model of the medical device into the depiction, wherein the model is positioned within the depiction relative to the identified insertion point.
“4. The method of claim 1, wherein the measurement(s) determined in the determining step further comprise: a distance between the point within the mitral plane corresponding to the centroid of the mitral annulus and the point within the offset mitral plane corresponding to the centroid of the mitral annulus.
“5. The method of claim 1, wherein the measurement(s) determined in the determining step comprise(s) at least one of: a distance between an origin of the mitral plane and an intersection point of the offset mitral plane and an offset fossa ovalis plane; a distance between an origin of the offset mitral plane and the intersection point of the offset mitral plane and the offset fossa ovalis plane; or an angle containing the origin of the mitral plane, the origin of the offset mitral plane, and the intersection point of the offset mitral plane and the offset fossa ovalis plane.
“6. A non-transitory, computer-readable storage medium storing instructions thereon that when executed by an electronic processor causes the electronic processor to carry out the method of: acquiring image data relating to an anatomical region of interest of a patient’s body; generating a multi-dimensional depiction of the anatomical region of interest using the acquired image data, wherein the multi-dimensional depiction includes three dimensions; defining a plurality of points relative to the multi-dimensional depiction, wherein at least two of the plurality of points correspond to a centroid of an anatomical structure of the patient’s body, and wherein the plurality of points comprises two or more of the following individual points: a point within a mitral plane that contains a mitral annulus of the patient’s heart, wherein the point corresponds to a centroid of the mitral annulus; a point within an offset mitral plane that is a duplicate of and offset from the mitral plane, wherein the point is offset from the point in the mitral plane and corresponds to the centroid of the mitral annulus; a point within a fossa ovalis plane that contains a fossa ovalis of the patient’s heart, wherein the point corresponds to a centroid of the fossa ovalis; and a point within an inferior vena cava (“IVC”) ostium plane that contains an IVC ostium of the patient’s heart, wherein the point corresponds to a centroid of the ostium of the IVC; determining, with the electronic processor, one or more measurements based on the defined plurality of points, wherein the measurement(s) determined in the determining step comprise(s) at least one of: an angle formed by the point within the IVC ostium plane corresponding to the centroid of the ostium of the IVC, the point within the fossa ovalis plane corresponding to the centroid of the fossa ovalis, and the point in the mitral plane corresponding to the centroid of the mitral annulus, wherein the point within the fossa ovalis plane corresponding to the centroid of the fossa ovalis is the vertex of the angle; or an angle formed by the point within the fossa ovalis plane corresponding to the centroid of the fossa ovalis, the point within the mitral plane corresponding to the centroid of the mitral annulus, and the point within the offset mitral plane corresponding to the centroid of the mitral annulus, wherein the point within the mitral plane corresponding to the centroid of the mitral annulus is the vertex of the angle, and selecting a medical device over another medical device based on the determined measurements, wherein the medical device is configured to fit into an insertion point of interest.
“7. The storage medium of claim 6, wherein the method carried out by the one or more processors further comprises: identifying in the depiction the insertion point along an interatrial septum; selecting a model representative of the medical device that will pass through the interatrial septum during the performance of the medical procedure; importing the model of the medical device into the depiction, wherein the model is positioned within the depiction relative to the identified insertion point; and evaluating feasibility of the insertion point, a type, shape, and/or size of the medical device, or both the feasibility of the insertion point and the type, shape, and/or size of the medical device based on a trajectory of the model of the medical device within the depiction.
“8. The storage medium of claim 6, wherein the method carried out by the one or more processors further comprises receiving at least one user input, and in response to that at least one user input, the method further comprises: identifying in the depiction the insertion point along an interatrial septum; selecting a model representative of the medical device that will pass through the interatrial septum during the performance of the medical procedure; importing the model of the medical device into the depiction, wherein the model is positioned within the depiction relative to the identified insertion point.
“9. The storage medium of claim 6, wherein the measurement(s) determined in the determining step further comprise: a distance between the point within the mitral plane corresponding to the centroid of the mitral annulus and the point within the offset mitral plane corresponding to the centroid of the mitral annulus.
“10. The storage medium of claim 6, wherein the measurement(s) determined in the determining step comprise(s) at least one of: a distance between an origin of the mitral plane and an intersection point of the offset mitral plane and an offset fossa ovalis plane; a distance between an origin of the offset mitral plane and the intersection point of the offset mitral plane and the offset fossa ovalis plane; or an angle containing the origin of the mitral plane, the origin of the offset mitral plane, and the intersection point of the offset mitral plane and the offset fossa ovalis plane.”
There are additional claims. Please visit full patent to read further.
For the URL and additional information on this patent, see: Forbes, Michael. Selecting a medical device for use in a medical procedure.
(Our reports deliver fact-based news of research and discoveries from around the world.)
