Patent Application Titled "Methods, Devices and Systems for Treating Insomnia by Inducing Frontal Cerebral Hypothermia" Published Online (USPTO 20150290420)

By a News Reporter-Staff News Editor at Politics & Government Week -- According to news reporting originating from Washington, D.C., by VerticalNews journalists, a patent application by the inventor NOFZINGER, Eric A. (Allison Park, PA), filed on June 24, 2015, was made available online on October 22, 2015.

No assignee for this patent application has been made.

Reporters obtained the following quote from the background information supplied by the inventors: "Insomnia is most often described as the inability to fall asleep easily, to stay asleep or to have quality sleep in an individual with adequate sleep opportunity. In the U.S., population-based estimates of either chronic or transient insomnia range from 10 to 40% of the population, or 30 to 120 million adults in the United States. Similar prevalence estimates have been reported in Europe and Asia. Across studies, there are two age peaks: 45-64 years of age and 85 years and older. Women are 1.3 to 2 times more likely to report trouble sleeping than men, as are those who are divorced or widowed, and have less education. In the U.S., the economic burden of insomnia approaches $100 billion, in direct health care costs, functional impairment, increased risk of mental health problems, lost productivity, worker absenteeism and excess health care utilization. It is recognized as a public health problem, contributing to more than twice the number of medical errors attributed to health care workers without insomnia episodes. Currently available treatments for insomnia, however, are not entirely satisfactory for a variety of reasons. Sedative-hypnotics are not a complete solution to the problem of insomnia as they are associated with significant adverse events such as the potential for addiction/dependence, memory loss, confusional arousals, sleep walking and problems with coordination that can lead to falls and hip fractures. The majority of insomnia patients would prefer a non-pharmaceutical approach to their insomnia complaints. Cognitive behavior therapy, while effective, is an expensive and labor intensive treatment that is not widely available and is not always covered by health insurance. Over-the-counter approaches to the treatment of insomnia including a variety of medications and devices suffer from inadequate clinical studies demonstrating significant effects in insomnia patients, as well as potentially dangerous side effects. A large need exists, therefore, for a safe, effective, non-invasive, non-pharmaceutical device for the treatment of insomnia.

"Recent advances have been made in the neurobiology of sleep and in the neurobiology of insomnia that can inform innovative treatments for insomnia. Considerable evidence suggests that sleep may serve a restorative function. An EEG marker of sleep homeostasis is EEG spectral power in the delta frequency range (1-4 Hz). The homeostatic sleep drive may involve the restoration of brain energy metabolism through the replenishment of brain glycogen stores that are depleted during wakefulness. This function may have some regional specificity. A frontal dominance of EEG spectral power in the delta EEG spectral power range has been reported. A frontal predominance for the increase in delta power following sleep loss has also been reported. This region of cortex plays a prominent role in waking executive functions which are preferentially impaired following sleep deprivation. Evidence such as this, suggests that sleep is essential for optimal executive behavior and that the mechanism involves the frontal cortex.

"'Hyperarousal', on a variety of physiological levels, represents the current leading pathophysiological model of insomnia. Insomnia patients have been shown to have increased whole brain metabolism across waking and sleep in relation to healthy subjects; resting metabolic rate, heart rate and sympathovagal tone in HRV, cortisol secretion in the evening and early sleep hours, beta EEG activity during NREM sleep, increased levels of cortical glucose metabolism, especially in the frontal cortex, associated with higher levels of wakefulness after sleep onset, impairments in the normal drop in core body temperature around the sleep onset period; and cognitive hyperarousal resting on the pre-sleep thoughts of insomnia patients, often described as 'racing,' unstoppable, and sleep-focused. Recent evidence also suggests that insomnia sufferers demonstrate selective attention directed toward sleep and bed-related stimuli, which may lead to a self-reinforcing feedback loop of conditioned arousal, poor sleep, and impaired waking function. Insomnia patients have demonstrated increases in beta EEG spectral power that correlate with increased metabolism in the ventromedial prefrontal cortex during NREM sleep. Improvements in sleep in insomnia patients have been associated with improvements in prefrontal cortex function as measured by functional neuroimaging.

"A decline in metabolism in the prefrontal cortex, therefore, appears to be important for the normal function of sleep and hypermetabolism in this region may interfere with this normal function of sleep in insomnia patients. Interventions designed to reduce elevated metabolism in the prefrontal cortex may improve sleep in insomnia patients.

"Several lines of evidence suggest that application of a cooling stimulus to the scalp may reduce metabolism in the cortex underlying the stimulus. Studies have shown that the application of a cooling stimulus to the scalp decreases brain temperature in the underlying cortex in both animals and humans. In a study in pigs, even a mild surface cooling of 15 degrees C. was associated with cooling of the scalp and superficial brain to 35 degrees C. In this study, there was a notable differential effect of surface cooling on superficial vs. deep brain tissue, with superficial brain tissue cooled to a greater degree than deep brain tissue. In a human study, Wang et al were able to decrease surface brain temperatures by an average of 1.84 degrees C. within 1 hour of subjects wearing a whole head cooling helmet. Biomedical engineering models demonstrate that cooling of the brain gray matter can be achieved by selective head cooling on the surface. These lines of evidence support the concept that application of a cooling stimulus at the scalp will be associated with reductions in metabolism in the underlying cortex.

"Cerebral hypothermia is an intervention that has previously been used to treat other medical disorders due to its neuroprotective effects. Therapeutic hypothermia after global and focal ischemic and other neurotoxic events such as head trauma, stroke and neuronal insult during cardiopulmonary surgery has shown beneficial results in controlled animal and human studies. Preclinical studies have shown many neuroprotective effects of brain cooling. These include: metabolism, pH, neurotransmitter levels, free fatty acids, blood-brain barrier, edema, glucose metabolism, cerebral blood flow, free radical activation, lipid peroxidation, calcium accumulation, protein synthesis, protein kinase-C activity, leukocyte accumulation, platelet function, NMDA neurotoxicity, growth factors, cytoskeletal proteins, calcium-dependent protein phosphorylation, heat shock protein, immediate early genes, NOS activity, and MMP expression. It is conceivable that the neuroprotective benefits of cerebral hypothermia may aid patients with sleep disorders, including insomnia. Pathophysiologic models of the adverse events associated with sleep disorders are beginning to focus on the potential neuronal toxicity of having a sleep disorder. That this may occur in insomnia is suggested by findings of hypercortisolemia in insomnia patients in the evening and early hours of sleep and known adverse effects of hypercortisolemia on neuronal function. One preliminary study has demonstrated reduced volumes of the hippocampus in insomnia patients. This may be the result of neurotoxic factors.

"Reducing hypermetabolism in the frontal cortex of insomnia patients during both the pre-sleep period and during sleep may reduce cognitive hyperarousal reported by insomnia patients. Cerebral localization of this is hypothesized to occur in the prefrontal cortex given its role in executive function and ruminative cognitions.

"Application of a cooling stimulus to the frontal scalp area may also facilitate the normative changes in thermoregulation associated with sleep onset. Heat loss, via selective vasodilatation of distal skin regions (measured by the distal minus proximal skin temperature gradient (DPG), seems to be a crucial process for the circadian regulation of core body temperature (CBT) and sleepiness. Increased DPG before lights off has been noted to promote a rapid onset of sleep, suggesting a link between thermoregulatory and arousal (sleepiness) systems. As noted above, impairments in the normal drop in core body temperature around the sleep onset period has been demonstrated in insomnia patients. A device that produces heat loss, especially through the periphery, therefore, may improve sleep in insomnia patients.

"Recent studies show that difficulty sleeping can be associated with increased brain metabolic activity especially in the frontal cortex. Patent application Ser. No. 11/788,694, filed Apr. 20, 2007, titled 'Method and Apparatus of Noninvasive, Regional Brain Thermal Stimuli for the Treatment of Neurological Disorders,' now U.S. Pat. No. 8,236,038, which was previously incorporated by reference, described a method and apparatus of noninvasive, regional brain thermal stimuli for the treatment of neurological disorders. Functional neuroimaging studies have shown that a noninvasive device applying a hypothermic stimulus to the scalp overlying the frontal cortex of the brain ('frontal hypothermia') reduced cerebral metabolic activity in insomnia patients during sleep, especially in the frontal cortex underlying the hypothermic pad. While these studies suggest that frontal hypothermia may be helpful in the clinical management of insomnia patients, the most appropriate parameters for the application of the device have not yet been fully worked out.

"Preliminary data using frontal hypothermia suggests that it reduces relative metabolism in a region of cerebral cortex underlying the scalp where the device is applied. Application of the device would not necessarily be limited to the condition of insomnia, but could be applied to diverse neuropsychiatric disorders, each of which may have insomnia as a contributing component or which may be characterized by its own abnormal pattern of cerebral metabolism.

"Several disorders have been shown to have insomnia as a co-morbid condition and/or relatively specific alterations in cerebral metabolism that may benefit from treatment with a frontal hypothermia device. These co-morbid conditions make medication treatment even more difficult, because these patients are often already on multiple other medications, some of which have sleep effects themselves. Co-morbid insomnia itself has been little studied with any form of treatment. Depression is associated with severe sleep disturbances including difficulty falling asleep, difficulty staying asleep, early morning awakening, or nonrestorative sleep. Functional neuroimaging studies have shown alterations in the normal reduction in prefrontal cortex metabolism from waking to NREM sleep. The lifetime prevalence of depression in the United States is 17.1% or currently 52 million individuals suggesting that this is a significant problem. The neurobiology of sleep problems in patients with chronic pain share significant overlaps with those of insomnia suggesting another medical disorder that may benefit from the frontal hypothermia device. The most common causes of pain that disrupt sleep include back pain (cost to society estimated to exceed $100 billion each year), headaches (50% of whom sleep disturbances trigger headaches and 71% of migraine sufferers have migraines that awaken them from sleep), fibromyalgia, and arthritis (osteoarthritis, rheumatoid arthritis and autoimmune diseases such as lupus). Chronic pain prevalence estimates in the United States are 10.1% for back pain, 7.1% for pain in the legs/feet, 4.1% for pain in the arms/hands, and 3.5% for headache. Chronic regional and widespread pain, are reported by 11.0% and 3.6% of respondents, respectively. Based on US Census data, this would translate into an additional market of over 50 million individuals. 70-91% of patients with post-traumatic stress disorder (PTSD) have difficulty falling or staying asleep. Medical treatments for the sleep problems in PTSD have revolved around medication management, which have associated adverse events. Studies conducted as part of the National Comorbidity Survey (NCS) have reported the prevalence of lifetime PTSD in the United States as 7.8 percent or currently a market of over 23 million individuals.

"Aside from a primary, stand alone therapy for insomnia, this device may also benefit insomnia patients who are partial responders to traditional sedative-hypnotic therapy for insomnia or from cognitive-behavior therapy for insomnia. While clinical trial data suggest that approved hypnotics show statistically significant improvements in about 2/3rds of patients, significantly fewer patients report full remission of symptoms. This suggests that about 2/3rds of patients who are prescribed hypnotics would be non-responders or partial responders to these treatments and as such may benefit from adjunctive therapy with frontal hypothermia insomnia device, such as the devices and systems described herein.

"Thus, there is a substantial need to provide methods, devices and systems for effectively creating frontal hypothermia to treat insomnia. The methods, devices and systems described herein may address many of the needs and issues described above."

In addition to obtaining background information on this patent application, VerticalNews editors also obtained the inventor's summary information for this patent application: "In general, described herein are methods, devices and systems for applying hypothermal therapy within highly controlled parameters to the skin over the prefrontal cortex in order to cool the prefrontal cortex and thereby reduce metabolism of this brain region. As described in greater detail below, hypothermic therapy of the prefrontal cortex may ameliorate insomnia. Thus, in many of the therapeutic methods described herein, a device or system includes an applicator having a thermal transfer region (e.g., pad, etc.) that is configured to contact, or be placed in thermal contact, with the patient's skin; specifically the skin over the prefrontal cortex. The applicator may be a mask or garment, and the thermal transfer region may be cooled and temperature controlled by any appropriate means, including fluid cooled (e.g., water cooled) or solid-state (e.g., Peltier device) or some combination thereof.

"For example, described herein are methods of treating insomnia by non-invasively applying hypothermal therapy to a subject's frontal cortex. The methods may include the steps of: positioning an applicator comprising a thermal transfer region in communication with the subject's skin over the prefrontal cortex; cooling the thermal transfer region to a first temperature consisting of the lowest temperature that may be tolerated by the subject without resulting in discomfort or arousal from sleep; maintaining the first temperature for a first time period extending at least 15 minutes prior to a target good night time; and maintaining a second temperature for a second time period extending at least 15 minutes after the target good night time.

"In some variations, the first temperature is between about 10.degree. C. and about 18.degree. C. In some variations, the first temperature (the coolest tolerable temperature) corresponds to the coolest temperature that may be applied by the applicator when worn by the subject and not cause irritation (or arousal); this temperature may be empirically or experimentally determined. For example, the method may include a step of determining the first temperature for the subject.

"The step of positioning the applicator may include securing the applicator in position. For example, the applicator may be held in position by straps. In some variations the applicator is adhesively secured. In general, the step of positioning the applicator may include securing the applicator over just the subject's forehead region. In some variations the applicator is limited to the forehead region.

"In some variations the step of cooling the thermal transfer region to a first temperature comprises ramping (including gradually ramping) the temperature of the thermal transfer region from ambient temperature to the first temperature over at least five minutes, ten minutes, 15 minutes, etc.

"The step of maintaining the first temperature may comprise holding the thermal transfer region at the first temperature for at least 30 minutes, one hour, etc.

"In some variations the first temperature is the same temperature as the second temperature (e.g., between 10.degree. C. and 18.degree. C.). However, in some variations the method includes the step of changing the temperature of the thermal transfer region to the second temperature. In general, the second temperature may be a temperature between the first temperature and 30.degree. C. For example, the second temperature may be between about 20.degree. C. and about 25.degree. C. The step of maintaining a second temperature for the second time may comprise maintaining the second temperature for more than one hour, 2 hours, 3 hours, 4 hours, 6 hours, 8 hours, or the entire sleep period. In some variations, the method further comprises adjusting the second temperature based on patient sleep-cycle feedback.

"Also described herein are methods of treating insomnia by non-invasively applying hypothermal therapy to a subject's frontal cortex, the method comprising: positioning an applicator comprising a thermal transfer region in communication with the subject's skin over the prefrontal cortex; cooling the thermal transfer region to a first temperature consisting of the lowest temperature that may be tolerated by the subject without resulting in discomfort or arousal from sleep; maintaining the first temperature for at least 15 minutes prior to a target good night time; maintaining the first temperature for at least 30 minutes after the target good night time; and maintaining the temperature at a second temperature between the first temperature and 30.degree. C. for at least 30 minutes.

"Also described herein are methods of reducing sleep onset by non-invasively applying hypothermal therapy to a subject's frontal cortex, the method comprising: positioning an applicator comprising a thermal transfer region in communication with the subject's skin over the prefrontal cortex; cooling the thermal transfer region to a first temperature between about 10.degree. C. and about 18.degree. C.; and maintaining the first temperature for a first time period extending at least 15 minutes prior to a target good night time.

"Also described herein are methods of sustaining sleep in a subject by non-invasively applying hypothermal therapy to the subject's frontal cortex, the method comprising: positioning an applicator comprising a thermal transfer region in communication with the subject's skin over the prefrontal cortex; after a target good night time, maintaining the thermal transfer region at a first temperature consisting of the lowest temperature that may be tolerated by the subject without resulting in discomfort or arousal from sleep; and maintaining the first temperature for a first time period extending at least 30 minutes after the target good night time. For example, the first temperature may be between about 10.degree. C. and about 18.degree. C.

"In general the methods of treating insomnia (e.g., by decreasing sleep latency and/or by increasing sustained sleep may be performed by non-invasive cooling, and particularly by cooling the skin over the frontal cortex. In some variations, this cooling is limited to forehead region. The systems and devices described herein generally control the profile of the hypothermal therapy applied so that both the temperature and timing of the dosage is controlled. The system may be configured to apply complex dosing regimens and may be further configured to modify or select the dosing regimen based on feedback from the patient. Feedback may be patient selected (e.g., by adjusting or changing a control input) or may be based of one or more sensors detecting physiological parameters from the patient, such as sleep level, REM/NREM state, or the like.

"As described in greater detail below the devices and systems for applying hypothermal therapy as described herein generally include an applicator (e.g., to be secured to or worn by the subject) having a thermal transfer region. The thermal transfer region is cooled. The thermal transfer region is also placed in contact with the skin over the subject's frontal cortex. In general, the applicator and thermal transfer region are configured so that the subject may comfortably and safely wear the device while sleeping or before sleeping (to increase drowsiness). The overall system may be configured to be quiet (so as not to disrupt sleep), and may include one or more controllers for regulating the temperature of the thermal transfer region, as mentioned above. The controller may be a microcontroller (including dedicated hardware, software, firmware, etc.). In some variations the system is configured to be worn by the subject every night, and thus may include a washable, disposable, or replaceable skin-contacting region. For example, the thermal transfer region may be covered by a disposable material or cover that can be replaced nightly with each use. In some variations one or more sensors may also be included to receive patient information and/or performance information on the system; this information may be provided to the controller and may be used to regulate the temperature. Overall, the system may be lightweight and easy to use.

"Other features of the invention described herein are outlined below in greater detail, and with reference to the figures.

BRIEF DESCRIPTION OF THE DRAWINGS

"FIG. 1A is a graph illustrating the increase in whole brain metabolism in insomnia during waking and sleep. FIG. 1B illustrates brain regions where insomnia patients do not show as great of a decline in relative metabolism from waking to sleep. FIG. 1C shows brain regions where relative metabolism is decreased in insomnia patients.

"FIG. 2A is a graph illustrating change in the average core body temperature over time in patients treated and un-treated using localized frontal hypothermia treatment.

"FIG. 2B shows PET scans of an insomniac patient undergoing treatment using frontal hypothermia and illustrating a reversal of prefrontal hypermetabolism.

"FIG. 3A shows a graph illustrating the decrease in subjective arousal in insomniac patients treated with prefrontal hypothermia as described herein.

"FIG. 3B shows a graph illustrating a decrease in whole brain metabolism (compared to control) in patients treated with prefrontal hypothermia.

"FIG. 3C shows a graph illustrating the increase in subjective sleepiness in insomniac patients treated with prefrontal hypothermia.

"FIG. 3D shows a graph illustrating the decrease a reduction in waking after sleep onset in patients treated with prefrontal hypothermia.

"FIG. 3E is a graph illustrating an increase in delta power during sleep in patients treated with prefrontal hypothermia.

"FIG. 3F is a side-by-side comparison of PET scans showing a reduction in regional metabolism in patients treated with prefrontal hypothermia.

"FIG. 4A shows one variation of a headpiece of a device for applying hypothermia. FIG. 4B illustrates the headpiece applied to a subject's head.

"FIG. 5A shows the effect of one variation of a device for applying prefrontal hypothermia on sleep onset latency in an insomniac patient compared to non-insomniac.

"FIG. 5B shows the effect of one variation of a device for applying prefrontal hypothermia on awake after sleep onset in an insomniac patient compared to non-insomniac.

"FIG. 5C shows the effect of one variation of a device for applying prefrontal hypothermia on wakefulness in the first half of the night in an insomniac patient compared to non-insomniac.

"FIG. 5D shows the effect of one variation of a device for applying prefrontal hypothermia on wakefulness in the second half of the night in an insomniac patient compared to non-insomniac.

"FIG. 5E shows the effect of one variation of a device for applying prefrontal hypothermia on total sleep time in an insomniac patient compared to non-insomniac.

"FIG. 5F shows the effect of one variation of a device for applying prefrontal hypothermia on sleep efficiency in an insomniac patient compared to non-insomniac.

"FIG. 5G shows the effect of one variation of a device for applying prefrontal hypothermia on the percentage of stage 1 sleep in an insomniac patient compared to non-insomniac.

"FIG. 5H shows the effect of one variation of a device for applying prefrontal hypothermia on the percentage of stage 2 sleep in an insomniac patient compared to non-insomniac.

"FIG. 5I shows the effect of one variation of a device for applying prefrontal hypothermia on the percentage of stages 3/4 sleep in an insomniac patient compared to non-insomniac.

"FIG. 5J shows the effect of one variation of a device for applying prefrontal hypothermia on the percentage of REM sleep in an insomniac patient compared to non-insomniac.

"FIG. 5K shows the effect of one variation of a device for applying prefrontal hypothermia on the number of whole night delta counts in an insomniac patient compared to non-insomniac.

"FIG. 5L shows the effect of one variation of a device for applying prefrontal hypothermia on the whole night spectral power in an insomniac patient compared to non-insomniac."

For more information, see this patent application: NOFZINGER, Eric A. Methods, Devices and Systems for Treating Insomnia by Inducing Frontal Cerebral Hypothermia. Filed June 24, 2015 and posted October 22, 2015. Patent URL: http://appft.uspto.gov/netacgi/nph-Parser?Sect1=PTO2&Sect2=HITOFF&u=%2Fnetahtml%2FPTO%2Fsearch-adv.html&r=6275&p=126&f=G&l=50&d=PG01&S1=20151015.PD.&OS=PD/20151015&RS=PD/20151015
